Platinum (Pt) Metal



l (nm)

n

k

200.0

1.24

1.34

310.0

1.49

2.25

413.3

1.75

2.92

459.2

1.87

3.20

516.6

2.03

3.54

563.6

2.17

3.77

619.9

2.30

4.07

652.5

2.38

4.26

729.3

2.63

4.63

826.5

2.92

5.07

953.7

3.29

5.61

1033.0

3.55

5.92

1512.0

5.17

7.01

2066.0

5.13

6.75

2455.0

3.91

7.71

3100.0

2.81

11.40

4133.0

3.92

16.20

5636.0

5.24

21.50

8266.0

8.18

31.20

12400.0

13.20

44.70
